Electropolishing behaviour and microstructures of copper deposits electroplated in an acidic copper-sulphuric bath with different thiourea contents

Ching An Huang, Jo Hsuan Chang

2014encopperelectropolishingthioureamicrostructureelectrodeposition

Abstract

Language:

Cu electrodeposition was performed on a rotating cylindrical Ti electrode in Cu-sulphate plating baths with different thiourea contents up to 8 ppm. The hardness, microstructure and electropolishing behaviour of the Cu deposits were studied. Some sulphur-rich particles in the Cu deposits prepared from the thiourea-containing baths were identified. The sulphur-rich particles dissolved preferentially during electropolishing in a 40 vol.% H3PO4 solution, forming a thin amorphous phase containing P in patches on the outer surface of the Cu deposit. The deposits prepared in the baths with thiourea showed higher dissolution current during polishing and formed a brightened and levelled surface with a surface roughness (Ra) lower than 30 nm.

Download

Cite This Work

@article{4edc65be-e852-4dac-8f1a-c801f40b5848,
  title={Electropolishing behaviour and microstructures of copper deposits electroplated in an acidic copper-sulphuric bath with different thiourea contents},
  author={Ching An Huang and Jo Hsuan Chang},
  year={2014},
  language={en}
}
TY  - JOUR
TI  - Electropolishing behaviour and microstructures of copper deposits electroplated in an acidic copper-sulphuric bath with different thiourea contents
AU  - Ching An Huang
AU  - Jo Hsuan Chang
PY  - 2014
LA  - en
ER  -
