Influence of halides on the dissolution and passivation behavior of AZ91D magnesium alloy in aqueous solutions

The electrochemical behavior of AZ91D in various aqueous sodium halide solutions was investigated using open-circuit potential (Eoc), potentiodynamic polarization and ac impedance (EIS) techniques. Generally, the results reveal that during immersion a protective layer of a salt film is formed on the alloy surface whose passivation performance depends on the halide nature, its concentration and temperature. Eoc shifts positively with time until attaining a steady (Est) value, which becomes less noble with increasing concentration or temperature of the test solution. At any given conditions, self-passivation was found to be favored in the order F− > I− > Br− > Cl−. This sequence is consistent with that for surface film resistance (RT) and its relative thickness (1/CT). Nevertheless, in F− medium each of the above parameters increases with [F−] up to a critical value of 0.3 M then decreases. Increasing concentration above 0.3 M induces large change in the microstructure of the outermost layer of the fluorinated extremely protective film and depassivation behavior predominates. In Br− and I− solutions, as well as the lower Cl− concentrations (≤0.01 M), AZ91D exhibits pseudo-passive state over the polarization range from the corrosion potential (Ecorr) to the knee point (Ept) in the anodic scan, at which passivity breakdown occurs with rapid increase in the anodic current and hydrogen gas reaction. At Cl− concentrations >0.01 M the negative difference effect (NDE) occurs under cathodic polarization where Ept lies negative to Ecorr. Addition of F− to the Cl− solution can induce large changes in the behavior of AZ91D.
